JXD is a professional company in air spring machines industry. It has been working in rubber industry for more than 20 years with professional knowledge and sufficient experiences. It makes the sales with combination of rubber products production technology and machinery technology....
Floor area
professionals
Founded
Machine dimension: L4600*W1550*H1900mm
Total power of the machine: 6KW
Power:400V, 50Hz
The equipment is mainly used for forming semi-finished rubber air spring. The machine including main base, machine body, spindle, forming table, pressing mechanism, infrared light control mechanism.
Compressed air: not less than 0.7Mpa.
Vacuum source: 0.08Mpa
For combined rolling lobe air spring bladder building, laminating and turn down & turn up.
Bladder diameter range: 160mm-240mm
Big ring ID:209mm-289mm
Small ring ID: 122.5mm-170mm
Air spring turn-up&turn-down machine technical specification
Servicer of the building machine
Air spring building machine
Curing press-high efficiency
Rolling Lobe Air Spring Curing Press
Jixiangdong is a professional company in rubber machines industry.
We have been working in air spring industry for more than 10 years with professional knowledge and sufficient experiences. It makes the sales with combination of products production technology and machinery technology.
We also can supply various non-standard rubber machines according to clients' different requirements. Our company guarantees to provide you excellent pre-market sales and after-sale services, timely technology information consulting, accessories and consumable parts supply.
Win-win cooperation is our target, your satisfaction is our final success. We sincerely welcome friends from all walks of life to come to visit and build business relationship to create bright achievement future.
We can supply all different air spring production machines, and with different automation level.
Our technical team is very experienced and can help customers from A to Z
Applicable air spring width: 450—900mm
Parallelism of two end after turn-up: ±3mm
Accuracy of two end after turn-up: ±3mm
Displacement accuracy: ±0.5mm
It adopts the single-stage building method (building and turn down & turn up are done on one machine) and automatic start the bladder turn down &turn up. Big ring uses mechanical rollers and the double-folded drum head to proceed the turn-up.
